This guide applies to Mac computers

​
About Sysdiagnose

A sysdiagnose in macOS collects diagnostic data for troubleshooting system issues. It gathers logs, crash reports, and system state from the Mac. You can generate a sysdiagnose in a few ways, depending on the user’s access level.

​
How It Works

Sysdiagnose collects system information used to diagnose issues: performance data, logs, hardware information, and system state.

​
What Sysdiagnose Collects

When you run sysdiagnose, it gathers an extensive array of information, including:
  • System-wide performance profiles - Captures the state of running processes
  • Filesystem activity logs - Reports on system calls and page faults related to filesystem usage
  • Process information - Provides detailed data on running processes and memory usage
  • Kernel memory usage - Includes data on kernel zones and loaded kernel extensions
  • System and crash logs - Collects all relevant logs to help diagnose issues
  • Hardware and software configuration - Similar to the System Information app, but more detailed
  • Network and power management data - Details on current network status and power settings

​
Generating a Sysdiagnose Using a Keyboard Shortcut

1

Open Finder

Click the Finder icon in the Dock to ensure that Finder is in the foreground.
2

Use keyboard shortcut

All at once, press Command + Option + Shift + Control + Period (.) on the keyboard.
3

Wait for completion

After a few moments, a Finder window should appear with a tar.gz file shown.
4

Provide to support

If the sysdiagnose was requested by Iru Endpoint Support, please zip it and provide the entire bundle.

​
Generating a Sysdiagnose Using the Command Line

This method requires administrator privileges.
1

Launch Terminal and run command

Launch Terminal.app and enter the following command:
2

Wait for file generation

Wait a few moments for a file ending in .tar.gz to appear on the logged-in user’s Desktop. If you logged into Terminal with a different user than is logged into the Mac, the file will be on the Terminal user’s Desktop.
3

Provide to support

If the sysdiagnose was requested by Iru Endpoint Support, please zip it and provide the entire bundle.

​
Generating a Sysdiagnose Using Activity Monitor

This method requires administrator privileges.
1

Open Activity Monitor

Open the Activity Monitor app on your Mac.
2

Access system diagnostics

Click the ellipsis at the top of the Activity Monitor window.Select System Diagnostics…
3

Accept privacy agreement

Read through and accept the privacy agreement.
4

Wait for completion

Wait for the progress bar to complete. Once done, a Finder window should appear with a tar.gz file shown.
5

Provide to support

If the sysdiagnose was requested by Iru Endpoint Support, please zip it and provide the entire bundle.
